HVS-1000Z Digital Micro Vickers Hardness Tester
1. Digital micro vickers hardness tester
2. Auto calculate hardness value
3. Digital display
4. Mini-printer
- Paglalarawan
- Pagtatanong
Paglalarawan
Mga Aplikasyon:
HVS-1000Z Digital Micro Vickers Hardness Tester is an economic hardness tester, it’s integrated the technology of optics, mechanics and computer. It’s has LCD screen, madaling operasyon. The testing result can be printed out by a mini-printer. It can automatically turning turret.
Technical specifications
Test Force | gf | 10, 25, 50, 100, 200, 300, 500, 1000 |
N | 0.098, 0.246, 0.49, 0.98, 1.96, 2.94, 4.90, 9.80 | |
Indentation Measurement | Digital Sensor Measurement | |
Loading Control | Awtomatikong (pag-load, dwell, pag alis ng load) | |
Magnification of Microscope | Observation: 10×; Measurement: 40× | |
Magnification of Eyepiece | 10× Eyepiece | |
Dwell Time | Adjustable 0-60s | |
Testing Range | 1 HV- 2967 HV | |
X-Y Anvil | Sukat: 100×100mm, Paglalakbay: 25×25mm, Resolusyon: 2M | |
Illumination | Adjustable LED light- source (Halogen is optional) | |
Max Height of Specimen | 100mm | |
Instrument Throat | 98m | |
Power Supply | AC 220V, 50Hz | |
Execution Standard | GB/T4340.2, EN-ISO6507, ASTM E10-18, ASME-384 | |
Overall Dimension | 480×305 ×545mm | |
Net Timbang | 30kg | |
