560RSSZ automatisk dobbel Rockwell hardhetstester
Automatic Rockwell Hardness Tester
Test: Rockwell and Superficial Rockwell
- Beskrivelse
- Forespørsel
Beskrivelse
560RSSZ automatisk dobbel Rockwell hardhetstester
(Automatic type, Rockwell and Superficial Rockwell, Berøringsskjerm)
Bruksområde:
Suitable for quenched steel, tempered steel, annealed steel, cold and hard casting, malleable cast iron, hard alloy steel, aluminum alloy, copper alloy, bearing steel etc. Also suitable for surface quenched steel, surface heat treating and chemical treating materials, sheet, zinc layers, chrome layers, tin layers etc.
Teknisk spesifikasjon:
| Modell | 560RSSZ |
| Innledende teststyrke | 3kgf (29.42N), 10kgf (98.07N) |
| Total Test Force | 15kgf (147.1N), 30kgf (294.2N), 45kgf (441.3N), 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N) |
| Indenter | Diamond Rockwell Indenter, ф1.588mmBall Indenter |
| Lastemetode | Automatisk (Lasting/dvele/lossing) |
| Automatic Test Table | Automatic Rising and Homing, One Key to Complete |
| Hardhetsavlesning | Berøringsskjerm |
| Test Scale | HRA, HRD, HRC, HRF, HRB, HRG, HRH, HRE, HRK, HRL, HRM, HRP, HRR, HRS, HRV HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HR15W, HR30W, HR45W, HR15X, HR30X, HR45X, HR15Y, HR30Y, HR45Y |
| Konverteringsskala | HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HBW |
| Datautgang | RS232 Interface |
| Oppløsning | 0.1HR |
| Dveletid | 0~99s |
| Maks. Høyde på prøven | 320mm |
| Hals | 150mm |
| Strømforsyning | AC220V，50Hz |
| Utfør standard | ISO 6508，ASTM E-18，JIS Z2245，GB/T 230.2 |
| Dimensjon | 535×330×890mm，Pakkedimensjon: 820×460×1170mm |
| Vekt | Nettovekt: 80kg，Bruttovekt: 100kg |
For mer detaljert info, værsåsnill kontakt oss: sales@victorytest.com
