ISO 9969 Plastic Pipe Ring Stiffness Testing Machine
- Paglalarawan
- Pagtatanong
Paglalarawan
ISO 9969 Plastic Pipe Ring Stiffness Testing Machine
Plastic Pipe Ring Stiffness Testing Machine 20kN 50kN 100kN
(20kN, 50kN, 100kN)
Mga Aplikasyon & Mga function
This WDW-50S Computerized Ring Stiffness Testing Machine is used to test the ring stiffness, ring softness and it’s inner deformation of plastic pipe. It also can do tensile strength and elongation test, bending test by adding relative test accessory.
The machine can meet ISO9969, ISO5893, ASTM D638, ASTM D790, ISO37, ASTM E4, ISO6892, ISO75000-1, EN 10002-4 standards and so on.
Equipped with the computer & Software & printer, it can display, record, process and print the test results, and control test procedures as the set program and can draw test curves automatically in real time. The PC controlling system can also realize the close-loop control of the parameters such as loading force, specimen deformation, and crosshead stroke etc. They are essential testing instrument for quality testing section, university and colleges, research institution and industrial and mining enterprise.
Pangunahing Teknikal na Mga Pagtutukoy:
| Modelo ng Parameter | WDW-50S |
| Saklaw ng Puwersa ng Pagsubok | 0.4kN- 50kN |
| Max Load Kapasidad | 50kN |
| Katumpakan ng puwersa | ±0.5% |
| Relative error of displacement measuring | ±0.5% |
| Resolusyon ng paglipat ng crosshead | ≥0.01mm |
| Crosshead paglipat ng bilis | 0.01-500mm / min |
| Effective compression testing space | 500mm (max na max. OD 500mm) or customized made |
| Lapad ng espasyo ng pagsubok | 400mm |
| Suplay ng kuryente | 1-Phase, 220V±10%, 50Hz |
| Sukat ng sukat L*W*H | 760×500×1800mm |
| Timbang | 450kg |
Inner deformation measuring device (Ring stiffness test):
This inner diameter deformation measuring device has resolution of 0.001mm, accuracy of ±0.2%.
Plastic Pipe Ring Stiffness Testing Machine 20kN 50kN 100kN
